Process Instruments Features & Benefits
Separator Design
Use an effective separator design (Dual Separator design with a vertical and horizontal Separator). Optimizing the gas/ liquid separation.
Accuracy & Metering Range
- Water cut range 0-100%.
- Sampler Water cut accuracy – 0.25% absolute.
- Gas flow accuracy – 2.0%.
- Liquid flow accuracy – 1%.
- Liquid Range: 10 – 12,000 Bbl./day (Middle East system).
Water Cut
- The water cut can be determined by using both the Coriolis meter (water and oil densities) and the isokinetic sampler.
- Multiple composite water cut samples per test period which have a volume weighted average. The sample is taken proportional to the flow rate.
- Follow API Manual of Petroleum Measurement Standards Chapter 8 -Sampling, Section 2 - Standard Practice for Automatic Sampling of Liquid Petroleum and Petroleum Products.
Operating System
Control System is an Allen Bradley ControlLogix with a SCADA operating system for the HMI. All results can be trended and reported in an Excel format. Data is emailed to the customer within 24 hours of test completion.
System Benefits
- Test results and meter diagnostics are analyzed to determine and assure a quality test before submission to the customer.
- On board lab for water cut analysis.
- H2S and Combustible gas detectors and SCBA are standard HSE equipment.
- Unit is self-contained and no resources other than the test schedule is required from the customer.
